MSD Servo Drive Compact Operation Manual
49
[Appendix ]
to the glossaryto the table of contents
Id no.: CA97555-001, Rev. 3.0 - Date: 0 6/2012
A.2 Technical data MSDServoDriveCompact
G394-030, G394-059 and G394-080
Designation
Technical data
G394-030 G394-059 G394-080
Output motor side
1)
Voltage 3 phase U
Mains
Continuous current effective (l
n
)
2)
3A 5.9A 8A
Peak current (A
effective
) see table A.1 and A.2
Rotating field frequency 0 ... 400Hz
Switching frequency of power
stage
4, 8, 16kHz
Input mains side
Mains voltage (1x230VAC / 3x230VAC) -20%/+15%
Device connected load
1)
(with mains choke)
1.3kVA 2.6kVA 3.5kVA
Current
1)
(with mains
choke)
1x230VAC 5.4A 10.6A 14.4A
3x230VAC
3.3A 6.5A 8.8A
Asymmetry of mains voltage ±3%maximum
Frequency 50/60Hz ±10%
Power loss at I
N
1)
75W 150W 200W
1) Data referred to output voltage 230VAC and switching frequency 8kHz.
2) For rated current refer to tableA .1 or tableA.2!
3) Connection of ext. braking resistor not permitted to devices with int. braking resistor (design G394-xxx-xxx-xx2)!
4) Braking resistor always integrated. Connection of an external resistor is permissible.
5) Option (G394-xxx-xxx-xx2)
Table A.4 Technical data G394-030, G394-059 and G394-080
Designation
Technical data
G394-030 G394-059 G394-080
DC link
Braking chopper switch-on
treshold
390VDC
Minimum ohmic resistance of
an externally installed braking
resistor
72 72
3)
72
3)
Brake chopper continuous power
with external braking resistor
2.1kW
Peak brake chopper with external
braking resistor
2.1kW
Internal braking resistor 550 (PTC)
4)
100
5)
90
5)
Brake chopper continuous power
with internal braking resistor
0W
depending on the effective load on the
drive in the specific application
Peak brake chopper with internal
braking resistor
400W 1500W 1700W
1) Data referred to output voltage 230VAC and switching frequency 8kHz.
2) For rated current refer to tableA .1 or tableA.2!
3) Connection of ext. braking resistor not permitted to devices with int. braking resistor (design G394-xxx-xxx-xx2)!
4) Braking resistor always integrated. Connection of an external resistor is permissible.
5) Option (G394-xxx-xxx-xx2)
Table A.4 Technical data G394-030, G394-059 and G394-080
NOTE: For more information on the braking chopper switch-on threshold also
refer to section 3.14 from page32.
