Moog G394-030

moog
MSD Servo Drive Compact Operation Manual
48
to the glossaryto the table of contents
Id no.: CA97555-001, Rev. 3.0 - Date: 0 6/2012
MSDServoDriveCompact for 3x400/460/480V
Device
Switching
frequency
of power
stage
Ambient
tempera-
ture
maximum
Rated current I
N
[A
eff
]
Peak current
2)
200% (2I
N
) 300% (3I
N
)
[kHz] [°C (°F)]
at
400V
at
460V
at
480V
[A
eff
]
for
time [s]
[A
eff
]
for
time [s]
G394-020
4 + 45 (+113) 2.0 2.0 2.0 4.0
10
6.0
0.088 +40 (+104) 2.0 2.0 1.7 4.0 6.0
1)
16 +40 (+10 4) 0.7 0.7 - 1.4 2.1
1)
G394-035
4 + 45 (+113) 3.5 3.5 3.5 7.0
10
10.5
0.088 +40 (+104) 3.5 3.5 2.6 7.0 10.5
1)
16 +40 (+10 4) 2.2 1.3 - 4.4 6.6
1)
G394-065
4 + 45 (+113) 6.5 6.5 6.5 13.0
10
19.5
0.088 +40 (+104) 6.5 6.5 6.5 13.0 19.5
1)
16 +40 (+10 4) 4.0 2.4 1.9 8.0 12.0
1)
1) Automatic power stage switching frequency change to 4kHz.
2) Data referred to 3x400V mains voltage
Data applies to motor cable length ≤10m. Maximum permissible motor cable length 30m.
Table A.3 Rated current and peak current C2 to C4 (3 x 400/460/480VAC)
