4.4.3 Parameter menu (PA)
On the Parameter menu the device settings can be reset to their factory defaults.
Menu level
Param-
eter
Value
range
Meaning Explanation
1 2
PA
Pr - - Parameter reset Reset device settings to factory defaults
Table 4.7 Parameter menu
Error numbers
A failed user action is indicated by an error message. The message consists of an
alternating display of "Er" and the error number.
NOTE: The error messages displayed during user input should not be
confused with drive error messages. For detailed information on the error
codes and on error management refer to the "MSDServoDrive Application
Manual".
Error number Meaning
17 Parameter reset to factory settings failed
18 Parameter write access failed
19 Save parameter data set non volatile failed
20 Not all parameters written
21 Error while reset to factory settings
Table 4.8 Error numbers
4.4.4 Ethernet IP-address menu (IP)
An Ethernet TCP/IP port is available as a service and diagnostics interface. The IP address
is set by default to 192.168.39.5 and the subnet mask to 255.255.255.0. Both can be
changed by way of the IP-address menu.
Menu level Pa-
ram-
eter
Value
range
Meaning Explanation
1 2
IP
Iu b0 00..FF IP address
update Byte0
Setting of byte 0 of the IP address in
hexadecimal format
(e.g. "05" at 192.168.39.5)
b1 00..FF IP address
update Byte1
Setting of byte 1 of the IP address in
hexadecimal format
(e.g. "27" at 192.168.39.5)
b2 00..FF IP address
update Byte2
Setting of byte 2 of the IP address in
hexadecimal format
(e.g. "A8" at 192.168.39.5)
b3 00..FF IP address
update Byte3
Setting of byte 3 of the IP address in
hexadecimal format
(e.g. "C0" at 192.168.39.5)
Ir - - IP reset to
factory setting
Reset IP address to factory default
(192.168.39.5)
Su b0 00..FF Subnetmask
update Byte0
Setting of byte0 of the subnet mask in
hexadecimal format
(e.g. "00" at 255.255.255.0)
b1 00..FF Subnetmask
update Byte1
Setting of byte1 of the subnet mask in
hexadecimal format
(e.g. "FF" at 255.255.255.0)
b2 00..FF Subnetmask
update Byte2
Setting of byte2 of the subnet mask in
hexadecimal format
(e.g. "FF" at 255.255.255.0)
b3 00..FF Subnetmask
update Byte3
Setting of byte3 of the subnet mask in
hexadecimal format
(e.g. "FF" at 255.255.255.0)
Sr - - Subnetmask
reset to
factory setting
Reset subnet mask to factory default
setting (255.255.255.0)
Table 4.9 IP-address menu
