Example configuration of subnet mask
In this example the subnet mask is changed from 255.255.255.0 to 122.255.255.0.
NOTE: Changes on the IP-address menu are only saved when the control
electronics are subsequently restarted.
T1
T2
Tx
Tx
Back
Back
Back
Apply
>5 s>5 s
<5 s
T2
<5 s
T1 T2
T1 T2
T1 T2
Back
T1 T2
Back
T1 T2
T1 T2
T1 T2
T1 T2
T1
T2
T1
T1
Back
T1 T2
T2
Press button
T
x
(X= 1,2) repeatedly
until desired menu
appears on display
Value NOT
saved
Value
saved
Press button
T
x
(X= 1,2) once
Press any button
Press buttons T1
and T2 simultaneously
Fig. 4.2 Example configuration of subnet mask
