MSD Servo Drive User Manual SERCOS II
16
The parameter listing in section 10.1 sets out the parameters that can be
written in the various phases.
LED H5 flash code Status
█▂█▂▂▂█▂█▂▂▂
H5H4
H5H4
Indication of communication phase 2
Table 3.3 Flash code: Communication phase 2
3.4 Communication phase 3
Communication phase 3 signifies that the drive is in restricted parameter-setting mode.
In this mode - as in parameter-setting mode (phase 2) - you can write to many param-
eters which are no longer editable in communication phase 4 (operation mode). No
communication parameters can be written in phase 3. During communication phase 3
the green LED H5 on the drive unit cyclically displays the flash code set out in the follow-
ing table.
LED H5 flash code Status
█▂█▂█▂▂▂█▂█▂█▂▂▂
H5H4
H5H4
Indication of communication
phase 3
Table 3.4 Flash code: Communication phase 3
3.5 Communication phase 4
Before the system can switch to communication phase 4, command S-0-0128 - “Prepare
switch to communication phase 4” - must be executed. During this preparatory phase
the drive checks criteria including the validity of the parameters required for communica-
tion phase 4. When the prepare-to-switch command has been successfully executed,
the drive is switched to communication phase 4 by the master. During communication
phase 4 the green LED H5 on the drive unit cyclically displays the flash code set out in
the following table. The drive can only be enabled via the control word in communica-
tion phase 4.
LED H5 flash code Status
█▂█▂█▂█▂▂▂█▂█▂█▂█▂▂▂
H5H4
H5H4
Indication of commu-
nication phase 4
Table 3.5 Flash code: Communication phase 4
