MSD Servo Drive User Manual SERCOS II
42
7.2 Weighting of velocity data
The velocity weighting is defined by the parameters listed in the following table. All
velocity data of the drive (e.g.: setpoint, actual and limit values) are subject to the preset
weighting. If “No weighting“ is selected via parameter S-0-0044, the weighting factor
and weighting exponent are irrelevant. The velocity data is then subject to a differently
defined weighting.
IDN Description
S-0-0044 Weighting method for velocity data
S-0-0045 Weighting factor for velocity data
S-0-0046 Weighting exponent for velocity data
Table 7.7 Scaling parameter for position weighting
7.2.1 Weighting of translatory velocity data
Translatory weighting is selected via S-0-0044. The significance of the LSB of the transla-
tory velocity data is defined by the following equation:
LSB significance =
Time unit
Travel unit
· S-0-0045•10
S-0-0046
When translatory preferential weighting is selected, the weighting as per the following
table applies.
Weighting method
(from S-0-0045)
Unit
(from S-0-0045)
Weighting
factor (S-0-0045)
Weighting
exponent (S-0-0046)
Preferential
weighting
Linear m/min 1 -6 0.001 mm/min
Table 7.8 Preferential weighting of translatory velocity data
7.2.2 Weighting of rotary velocity data
Rotary weighting is selected via S-0-0044. The significance of the LSB of the rotary
velocity data is defined by the following equation:
LSB significance =
Time unit
Travel unit
· S-0-0045•10
S-0-0046
When rotary preferential weighting is selected, the weighting as per the following table
applies.
Weighting method
(from S-0-0045)
Unit
(from S-0-0045)
Weighting
factor (S-0-0045)
Weighting
exponent (S-0-0046)
Preferential
weighting
Rotary rpm 1 -4 0.001 1/min
Rotary 1/s 1 -6 0.000 001 1/s
Table 7.9 Preferential weighting of rotary position data
Bit 2-0
Weighting method
0 0 0 No weighting
0 0 1 Translatory weighting
0 1 0 Rotary weighting
Bit 3
Weighting method
0 Preferential weighting
1 Parameter weighting
Bit 4
Distance unit
0 Revolutions (for rotary weighting) / Metres (for translatory weighting)
1 Reserved (for rotary weighting) / Inches (for translatory weighting)
Bit 5
Time unit
0 Minutes (min)
1 Seconds (s)
Bit 6
Data source
0 On the motor shaft
1 On the load side
Bit 7-17
Reserved
Table 7.10 Bit fields in the velocity data weighting method parameter (S-0-0045)
