Motorola ASTRO Digital Saber User Manual

1
-
11
ASTRO Digital
SABER Detailed
Model Chart
Model Number Description
H04KDC9PW5AN VHF 1-5 Watt ASTRO Digital SABER Model I
H04KDF9PW7AN VHF 1-5 Watt ASTRO Digital SABER Model II
H04KDH9PW7AN VHF 1-5 Watt ASTRO Digital SABER Model III
H04RDC9PW5AN UHF 1-4 Watt ASTRO Digital SABER Model I
H04RDF9PW7AN UHF 1-4 Watt ASTRO Digital SABER Model II
H04RDH9PW7AN UHF 1-4 Watt ASTRO Digital SABER Model III
H04SDC9PW5AN UHF 1-4 Watt ASTRO Digital SABER Model I
H04SDF9PW7AN UHF 1-4 Watt ASTRO Digital SABER Model II
H04SDH9PW7AN UHF 1-4 Watt ASTRO Digital SABER Model III
H04UCC9PW5AN 800MHz 1-3 Watt ASTRO Digital SABER Model I
H04UCF9PW7AN 800MHz 1-3 Watt ASTRO Digital SABER Model II
H04UCH9PW7AN 800MHz 1-3 Watt ASTRO Digital SABER Model III
Item Number Description
XXXXNHN6544_ Housing (with display and 3 x 6 keypad)
X X X X NHN6554_ Housing (with display and 3 x 2 keypad)
XXXXNHN6555_ Housing (no display and no keypad)
X X X NLD8892_ VHF Transceiver Board (136-174MHz)
XXX NLE4560_ UHF Transceiver Board (403-470MHz)
X X X NLE4244_ UHF Transceiver Board (450-512MHz)
XXXNUF6411_ 800MHz Transceiver Board (806-870MHz)
X X X X X X X X X X X X NTN4595_ Nickel-Cadmium, Ultra-High Capacity
(1800mAh), Large-Size Housing (Height 3.9” )
Battery
XXXXXXXXXXXXNTN7061_ Accessory Connector Cover
X X X X X X X X X X X X NTN7268_ Control Top Chassis
XXXXXXXXXXXXNTN7309_ Belt Clip
X X X X NTN7637_ Non-Display Front Shield
XX XX XX XXNTN7638_ Display Front Shield
X X X X X X X X X X X X NTN7749_ VOCON Kit
XXXXXXXXXXXX0305150X01 VOCON Shield Screws (qty. 4)
X X X X X X X X X X X X 1302646J01 Control Top Escutcheon
XXXXXXXXXXXX1302647J01 16-Position Select Knob Escutcheon
X X X X X X X X X X X X 2605403X01 VOCON Board Back Shield
XXXXXXXXXXXX2605535W02 Center Transceiver Shield
X X X X X X X X X X X X 2605844V01 VOCON Board Top Shield
XXXXXXXXXXXX2805462X01 20-Pin Mating Plug
X X X X X X X X X X X X 3205082E48 On/Off/Volume Control Knob O-Ring Gasket
XXXXXXXXXXXX3205082E80 Control Top O-Ring Gasket
X X X X X X X X X X X X 3205082E83 Programmable Button O-Ring Gasket
XXXXXXXXXXXX4502640J01 2-Position A/B Switch
X X X 8505518V01 VHF Antenna
XXXXXX 8505241U05 UHF Antenna
X X X 8505241U03 800MHz Antenna
X = Indicates one of each is required.
