Motorola ASTRO Digital Saber User Manual

12
-
3
Table 7 . J801
VOCON Board to Encryption Board
J801 Pin # Description To/From
1 SW B+ J401-17
2 SW B+ J401-17
3 EMC RXO U405-B7
4 EMC TXO U405-A7
5 n/c
6 GROUND
7 MISO U204-H6
8 MOSI U204-J6
J601-1
9 SPI SCK U204-G5
J601-2
10 EMC EN* U206-D6
11 EMC REQ* U206-H3
12 EMC MAKEUP* U206-K7
13 n/c
14 n/c
15 KEYFAIL*/RTSIN* U206-J8
16 n/c
17 n/c
18 n/c
19 n/c
20 UNSW B+ J401-19
21 GROUND
22 GROUND
23 n/c
24 n/c
25 n/c
Table 8 . J901
VOCON Board to Control Top Flex
J901 Pin # Description To/From
1 UNSW B+ J401-19
2 TG1/PROG SWITCH U204-D3
3 VOL U204-C3
4 EMERG U204-A3
5 +5V U409-12
6 INT PTT* U204-H2
7 RTA3 U206-H1
8 GRN LED DRIVER U206-E8
9 TG2 A/B SWITCH* U204-A2
10 B+ SENSE
11 RTA0 U206-F3
12 RED LED DRIVER U206-H9
13 RTA1 U206-F4
14 GROUND
15 RTA2* U206-F2
16 n/c
17 n/c
18 n/c
19 n/c
20 UNSW B+ J401-19
21 GROUND
22 GROUND
23 n/c
24 n/c
25 n/c
