Table 4 . J601
VOCON Board to Display Board
J601 Pin # Description
To/
From
1
MOSI U204-J6
J801-8
J401-9
2
SPI SCK U204-G5
J801-9
J401-10
3
SW B+ J401-17
4 DISP EN*/
LATCH SEL*
U206-G8
5 DISP RST* U204-F5
6 BL EN U206-E7
7 +5V U409-12
8 n/c
9 +5V U709-9
Table 5 . J701
VOCON Board to Keypad
J701 Pin # Description To/From
1 ROW 5/5V-EN* U206-F8
2 GROUND/MIC
RETURN
3 ROW 2/SPK EN U206-G4
4 INT MIC U411-2
5 COL2 U206-D5
6 COL3/MOB IRQ* U206-B4
7 GROUND
8 n/c
9 ROW4/TXPA EN* U206-G9
10 COL1 U206-A7
11 ROW3/BUSY OUT U206-K8
12 ROW6/MIC EN U206-G7
13 ROW1 U206-J3
14 SPKR COMMON U401-A3
J201-11
U401-A3
U204-B3
15 INT SPKR U401-B2
Table 6 . J1/J401
Transceiver Board to VOCON Board
J1/
J401
Pin
#
Description
Transceievr
Board
VOCON
Board
1 DOUT* U401-4 U406-H3
2 DOUT U401-5 U406-K3
3 GROUND
4 SBI U401-6 U406-J3
5 GROUND
6 POR*RSSI U305-5
U503-19
U407-1
7 DA SEL* DA
CE
U503-16 U204-H5
8 ODC 2.4MHz U401-7 U406-F3
9 MOSI DATA U503-18
U302-2
U304-25
10 SPI SCK* U503-17
U302-3
U304-22
(CLOCK)
U204-G5
11 ROSC/PSC CE* U304-24
(REF OSC
EN)
U204-F6
12 GROUND
13 LOCK DET* U302-41
CR502
U206-K2
14 SYN SEL* U302-4
(SYN CE)
U204-H7
15 MOD IN U302-5 U406-B2
16 GROUND
17 SW B+ U305-8 U409,
J801-1,
Q206
18 GROUND
19 UNSW B+ J3-1
U105-5
U502-6
(RAW B+)
U409-1
20 UNSW B+ J3-1
U105-5
U502-6
(RAW B+)
J801-20
U409-1
Q207
