Standard Bias
Table
Table 3, below, outlines some standard supply voltages and system clocks
which should be present under normal operation. These should be checked as
a first step to any troubleshooting procedure.
Table 2 . Standard Operating Bias
Signal Name Nominal Value Tolerance Source
UNSW_B+ 7.5Vdc 6.0-9.0Vdc J401
SW_B+ 7.5Vdc 6.0-9.0Vdc Q207
+5V
+5VA
5.0Vdc
5.0Vdc
±10%
±10%
U409
U410
RESET 5.0Vdc +0.7, - 1.0Vdc U407
POR* 5.0Vdc +0.7, - 1.0Vdc U206
DSP_RST*
ADSIC_RST*
5.0Vdc
5.0Vdc
+0.7, -1.0Vdc
+0.7, -1.0Vdc
U204
U204
DCLK 33.0000MHz
a
a. This is number may vary due to the operating mode of the radio when
it is measured. The ADSIC contains a divider which may divide the
clock by a modulus of 2. Therefore the actual frequency measured
may be clock/2
n
. The most common frequency will be 16.5000MHz
nominal.
±500ppM U406
ODC 2.4MHz ±30ppM ABACUS
ECLK
IRQB*
1.8432MHz
8kHz
b
b. This 8kHz clock will be present only after the MCU has successfully pro-
grammed the ADSIC after power-up. This is a good indication that the
ADSIC is at least marginally operational.
±500ppM
±500ppM
U204
U406
+5V 5.0Vdc ±10% U202
RX_5V
c
c. Receive mode only.
5.0Vdc ±10% U106
