Symbologies
4 - 55
Set Lengths for MSI (continued)
NOTE
Due to the construction of the MSI symbology
, it is
possible for a scan line
covering only a portion of the
code to transmit as a complete scan, yielding less dat
a than
is encoded in the
bar code. T
o prevent this,
select specific lengths (
MSI - One Discrete
Leng
th, T
wo Discrete Lengths
) for MSI ap
plications.
MSI - One Discret
e Length
MSI - T
wo Discrete L
engths
MSI - Length Wi
thin Range
MSI - Any Length
112
114
