CS4070 Scanner Product Reference Guide
GS1 DataBar
The variant
s of
GS1 DataBar are Dat
aBar-14, DataBar Exp
anded, and DataBar Limited. The limited and
expanded versio
ns have s
tacked variants. Scan
the appr
opriate bar codes to enable or disable each
variant of
GS1 DataBar
.
GS1 DataBar
-14
Parameter # 338
GS1 DataBar Limited
Parameter # 339
*
Enable GS1 Dat
aBar-14
(1)
Disable GS1 Dat
aBar-14
(0)
Enable GS1 DataBar Limited
(1)
*
Disable GS1 Dat
aBar Limited
(0)
121
123
