1 - 8 CS4070 Scanner Product Reference Guide
Editing the Configuration File
Use a text editor such as Notepad to set configuration values in the Config.ini editable text file in the
\Parameters folder on the CS4070. Table 1-1 lists the programmable contents of the file.
NOTE If you make errors while editing the Config.ini file, the file LOG.TXT is created in the \Parameters folder.
Consult this log file to determine the errors and make corrections.
Table 1-1 Config.ini File Content
Parameter Values Description Default
BarcodeFile String In batch mode, the name of the batch file
containing bar codes scanned.
BARCODES.TXT
BarcodeDB String Bar code database filename. If the file
exists scanned bar codes are checked
against its content. If the bar code exists
within the database, the scanner issues a
positive beep, if not a negative beep.
To engage this mode, create the
BarcodeDB.txt file on the CS4070. Note
that if this mode is engaged, no bar code
data is saved to the scanner.
DBASE.TXT
BTPin String Default SPP PIN. 1234
BTName String Bluetooth device name (address) used
during discovery.
CS4070:<serial
number>
BTProfile HID
SPP
Selected BT profile. HID
BeepVolume Low
Medium
High
Beeper volume. High
BeepTone Low
Medium
High
Beeper tone/frequency. Medium
Mute On
Off
Mute the beeper. Off
WakeUpBeep Enable
Disable
Enable or disable the wake up beeper. Disable
Prefix Character Prefix character. <none>
Suffix Character Suffix character. 0x0D (CR)
Separator Character Separator character. ','
DateFormat MM/DD/YY
DD/MM/YY
MM/DD/YYYY
DD/MM/YYYY
Date format for batch data. Set to enable
date stamp . See Set Date on page 3-5 to
set the date.
Enter no value to disable the date stamp,
for example: “
DateFormat = “
MM/DD/YY
(Enable)
