Chemgard Infrared Gas Monitor
Appendix C, RS-232 Output
Table C-1. RS-232 Parameters
COMMUNICATION
PARAMETERS
Appendix C
RS-232 Output
Introduction
Your Chemgard Infrared Gas Monitor is ordered
and built for the particular types of gas in use.
The monitor full scale range may differ from the
standard 0 to 1000 ppm range. Check the
calibration label on the reverse side of the front
cover (FIGURE C-1) to determine your
instrument’s full scale range.
The instrument is ready to monitor; however, it is
necessary to configure the unit to your specific
requirements. Your Chemgard Infrared Gas
Monitor may contain an internal
Multi-Point
Sequencer, enabling your unit to sample from up
to eight individual sampling locations.
Your unit also contains several other features
described in this appendix:
•
RS-232 output
•
Password protection
•
Remote Front Panel capability
•
Sampling point identification.
Figure C-1. RS-232 Location
