Table 1-6. SW3 Switch Settings
NOTE: LEFT side of each SW3 Dip Switch indicates the ON position and
RIGHT side of each SW3 Dip Switch indicates the OFF position.
NUMBER FUNCTION
1
SPARE (LEAVE IN OFF POSITION)
2
SPARE
3
OFF DELAY ON/OFF - CAUTION
4
OFF DELAY ON/OFF - WARNING
5
OFF DELAY ON/OFF - ALARM
6
*OFF DELAY TIME - BIT2
7
*OFF DELAY TIME - BIT1
8
*OFF DELAY TIME - BIT0
NOTE: The delay time selected via switches 6 - 8
will apply to any delay switch(es) 3 - 5 in the ON position.
*OFF DELAY TIME
BIT2 BIT1 BIT0
TIME
(IN SECONDS)
OFF OFF OFF 5
OFF OFF ON 15
OFF ON OFF 30
OFF ON ON 60
ON OFF OFF 90
ON OFF ON 120
ON ON OFF 150
ON ON ON 180
Controller/Calibrator Operation
The Toxgard II Monitor is fully compatible with the Ultima
Controller and the Ultima Calibrator. These devices can be used
to set various parameters in the Toxgard II Monitor, including
alarm conditions, auto calibration configuration, etc.
The devices can also be used for calibrating the Toxgard II
Monitor. When using these devices, point them at the front panel
of the Toxgard II Monitor, aiming directly at the triangular IR
symbol (located next to the word "WARNING" at the center of
Chapter 1, Set-up
1-24
