MSA Toxgard II User Manual

Appendix A
Optional Duct Mount Kit
General
The Remote Sensor Duct Mount Kit (FIGURE A-1) provides
convenient sampling of gas within an air duct.
• This Kit enables duct gas sampling even when flow rate within
the duct is at a high velocity.
• The user can calibrate the sensor via a calibration port without
disassembling or removing the sensor from the duct.
• The sensor and the Kit are sealed to the duct to prevent gas
within the duct from escaping.
• All Toxgard II remote sensors fit into the remote sensor model
of the Duct Mount Kit.
The Remote Sensor Module Duct Mount Kit:
• Allows the sensor portion of the unit to be mounted on the duct
(perhaps in an inaccessible location), while the read-out and
calibration portion are placed in an easily accessible location to:
Figure A-1.
Ultima Duct Mount Kit
Appendix A, Optional Toxgard II Duct Mount Kit
A-1
