Toxgard II Gas Monitor Calibration
The only true check of any gas monitor’s performance is to apply
gas directly to the sensor. The calibration procedure must be
performed regularly.
Calibration Documentation
The Toxgard II Monitor records the date of the last successful
calibration. This date can then be displayed on the front-panel
LED (with the use of the Controller) or transmitted to a
Figure 3-5. Calibration Kit 54 Contents
(Your Kit may also include one or two gas cylinders)
NOTE: Item 5 (P/N 10066581) is used only for SAFEMTX Calibration
Item 1 - Tubing (P/N 711112)
- 3/16" ID side connects to Item 3;
- 1/4" ID side connects to sensor
Item 2 - Zero Cap
(P/N 710535)
Item 3 - 1.5 LPM
Flow Controller
(P/N 478358)
Item 5 - Calibration Cover Assembly
(P/N 10066581)
Item 4 - Desiccant
(P/N 10064306)
Chapter 3, Calibration
3-6
