• save valuable maintenance time and money
• enhance calibrator safety.
Mounting
General
Mounting the Remote Sensor on a duct is easily done with the
Duct Mount Kit. The proper location on the duct will permit your
sensor to operate up to its potential.
Choose a location on the duct:
• Where the duct is flat or level:
• The Duct Mount Kit will not mount on a diameter of less
than eight inches (203 mm) of rounded or
curved duct work.
• Additional gasketing may be necessary to properly seal
the unit.
• As far away from any bends or tees as possible, as those
locations may have additional turbulence
• Where reasonable access is possible to enable
sensor replacement
• That keeps the sensor pointing downward:
• It is good practice to mount the sensor on horizontal run
of the duct.
• Mount the sensor on top of the duct to allow water and
dirt to naturally drip off the sensor within the duct and
prevent clogging.
• That allows the dual module sensor calibration gas tubing to be
routed to the read-out module. Any gas-compatible tubing can
be used (not supplied in Kit).
• Keep this tubing as straight and short as possible.
• Beyond any filter or cleaning unit.
• Away from the lowest point on the duct, which tends to collect
additional dirt and dust.
• Away from any fans or blowers.
The Duct Mount Kit requires some assembly before mounting. It
is necessary to temporarily remove the sensor from the module
housing and install the sealing gaskets. All necessary hardware is
provided in the Kit.
Appendix A, Optional Toxgard II Duct Mount Kit
A-2
