For systems that use five-digit addressing, 4XXXX:
If the first digit is an internal system requirement and does not appear in the
communications packet, write the value 1000 to address 41000.
The base address is now 41000 and the first valid address is 41001.
If all five digits appear in the communications packet, the default base address
is 40000 and the first valid address is 40001.
For systems that use six-digit addressing, 4XXXXX:
The first digit is an internal system requirement and does not appear in the
communications packet. The base address is 440000, and the first valid
address is 440001.
4.7. ModBUS Factory Configuration Data (Read Only)
Description Address Possible Value
Device Type Base +1 3 (ULTIMA X3 US);
4 (ULTIMA X3 Europe)
Firmware Version Base +2
00.00 to 99.99
0..32767 integer
divide by 100 for range
Relays Option Installed Base +3 0 - Relays not installed
1 - Relays installed
Reserved for future use Base +4
Sensor 1, Date of Mfg Year, Base +5 20XX
Sensor 1, Date of Mfg Month, Base +6 1 … 12
Sensor 1, Date of Mfg Day, Base +7 1 … 31
Sensor 2, Date of Mfg Year, Base +8 20XX
Sensor 2, Date of Mfg Month, Base +9 1 … 12
Sensor 2, Date of Mfg Day, Base +10 1 … 31
Sensor 3, Date of Mfg Year, Base +11 20XX
Sensor 3, Date of Mfg Month, Base +12 1 ... 12
Sensor 3, Date of Mfg Day, Base +13 1 … 31
Full Scale Range Sensor 1 Base +14 Single Precision Float
Full Scale Range Sensor 2 Base +16 Single Precision Float
Full Scale Range Sensor 3 Base +18 Single Precision Float
