MSA MODBUS USER CONFIGURATION DATA
ULTIMA
®
X
3 TM
29
B-2. Alarm Function Codes - Word 1 (Read/Write at Address Base +137)
Name Bits Function Description
Alarm 1 Enable, Sensor 1,
0
1 - Enable, 0 - Disable
Alarm 1 Enable, Sensor 2,
1
1 - Enable, 0 - Disable
Alarm 1 Enable, Sensor 3
2
1 - Enable, 0 - Disable
Alarm 2 Enable, Sensor 1
3
1 - Enable, 0 - Disable
Alarm 2 Enable, Sensor 2
4
1 - Enable, 0 - Disable
Alarm 2 Enable, Sensor 3
5
1 - Enable, 0 - Disable
Alarm 3 Enable, Sensor 1
6
1 - Enable, 0 - Disable
Alarm 3 Enable Sensor 2
7
1 - Enable, 0 - Disable
Alarm 3 Enable Sensor 3
8
1 - Enable, 0 - Disable
Alarm 1 Direction, Sensor 1,
9
1 - Increasing, 0 - Decreasing
Alarm 1 Direction, Sensor 2
10
1 - Increasing, 0 - Decreasing
Alarm 1 Direction, Sensor 3
11
1 - Increasing, 0 - Decreasing
Alarm 2 Direction, Sensor 1
12
1 - Increasing, 0 - Decreasing
Alarm 2 Direction, Sensor 2
13
1 - Increasing, 0 - Decreasing
Alarm 2 Direction, Sensor 3
14
1 - Increasing, 0 - Decreasing
Not used
15
B-3. Alarm Function Codes - Word 2 (Read/Write at Address Base +138)
Name Bits Function Description
Alarm 3 Direction, Sensor 1
0
1 - Increasing, 0 - Decreasing
Alarm 3 Direction, Sensor 2
1
1 - Increasing, 0 - Decreasing
Alarm 3 Direction, Sensor 3
2
1 - Increasing, 0 - Decreasing
Alarm 1 Latch Status, Sensor 1
3
0 - Non-Latching, 1 - Latching
Alarm 1 Latch Status, Sensor 2
4
0 - Non-Latching, 1 - Latching
Alarm 1 Latch Status, Sensor 3
5
0 - Non-Latching, 1 - Latching
Alarm 2 Latch Status, Sensor 1
6
0 - Non-Latching, 1 - Latching
Alarm 2 Latch Status, Sensor 2
7
0 - Non-Latching, 1 - Latching
Alarm 2 Latch Status, Sensor 3
8
0 - Non-Latching, 1 - Latching
Alarm 3 Latch Status, Sensor 1
9
0 - Non-Latching, 1 - Latching
Alarm 3 Latch Status, Sensor 2
10
0 - Non-Latching, 1 - Latching
Alarm 3 Latch Status, Sensor 3
11
0 - Non-Latching, 1 - Latching
Relay State NO-Alarm
12
1 - Normally Energised,
2 - Normally De-Energised
Relay State NO-Alarm
13
1 - Normally Energised,
2 - Normally De-Energised
Relay State NO-Alarm
14
1 - Normally Energised,
2 - Normally De-Energised
Not used
15

MSA Ultima X Specifications

General

Ingress Protection	IP66/67
Enclosure	Explosion-proof
Detection Method	Electrochemical, Infrared, Catalytic Bead
Gases Detected	Combustible gases, Toxic gases, Oxygen
Display	LCD
Output	4-20 mA, HART
Housing Material	Stainless steel
Certifications	ATEX, IECEx, UL, CSA, SIL 2
