B-6. ModBUS Fault Status Bits (Read only at Address Base +202)
Name Bit Function Description
Fault Relay Active
0
Set when any fault is detected
Sensor Missing - Sensor 1
1
Set when any fault is detected
Sensor Missing - Sensor 2
2
Set when any fault is detected
Sensor Missing - Sensor 3
3
Set when any fault is detected
Calibration Fault - Sensor 1
4
Set when any fault is detected
Calibration Fault - Sensor 2
5
Set when any fault is detected
Calibration Fault - Sensor 3
6
Set when any fault is detected
Power Fail Fault - Sensor 1
7
Set when any fault is detected
Power Fail Fault - Sensor 2
8
Set when any fault is detected
Power Fail Fault - Sensor 3
9
Set when any fault is detected
Power Fail Fault - Main Unit +5V DC
10
Set when any fault is detected
Sensor End of life - Sensor 1
11
Set when any fault is detected
Sensor End of life - Sensor 2
12
Set when any fault is detected
Sensor End of life - Sensor 3
13
Set when any fault is detected
ULTIMA X Configuration Reset
14
Set when a datasheet reset occurs
Not used
15
B-7. Control Words (Read/Write)
Description Address Possible Values
Command Word 1 Base +301 0 to 32767,
See Appendix B-8
Command Word 2 Base +302 0 to 32767,
See Appendix B-9
