MSA Ultima X User Manual

GB
MODBUS USER CONFIGURATION DATA MSA
36 ULTIMA
®
X
3 TM
B-14. Information Flags Word 3 (Read at Address Base +256)
Name Bits Function Description
Overrange Flag Sensor 1 0 Set if TRUE
Overrange Flag Sensor 2 1 Set if TRUE
Overrange Flag Sensor 3 2 Set if TRUE
LOC Flag Sensor 1 3 Set if TRUE
LOC Flag Sensor 2 4 Set if TRUE
LOC Flag Sensor 3 5 Set if TRUE
Parameter Fault Sensor 1 6 Set if TRUE
Parameter Fault Sensor 2 7 Set if TRUE
Parameter Fault Sensor 3 8 Set if TRUE
Warm Up Sensor 1 9 Set if TRUE
Warm Up Sensor 2 10 Set if TRUE
Warm Up Sensor 3 11 Set if TRUE
Sensor Configuration Reset 1 12 Set if TRUE
Sensor Configuration Reset 2 13 Set if TRUE
Sensor Configuration Reset 3 14 Set if TRUE
Not Used 15
B-15. Information Flags Word 4 (Read at Address Base +257)
Name Bits Function Description
Underrange Average Interval Sensor 1 0 Set if TRUE
Underrange Average Interval Sensor 2 1 Set if TRUE
Underrange Average Interval Sensor 3 2 Set if TRUE
Overrange Average Interval Sensor 1 3 Set if TRUE
Overrange Average Interval Sensor 2 4 Set if TRUE
Overrange Average Interval Sensor 3 5 Set if TRUE
Sensor Warning Sensor 1 6 Set if TRUE
Sensor Warning Sensor 2 7 Set if TRUE
Sensor Warning Sensor 3 8 Set if TRUE
Not Used 9
Not Used 10
Not Used 11
Not Used 12
Not Used 13
Not Used 14
Not Used 15

MSA Ultima X Specifications

General

Ingress Protection	IP66/67
Enclosure	Explosion-proof
Detection Method	Electrochemical, Infrared, Catalytic Bead
Gases Detected	Combustible gases, Toxic gases, Oxygen
Display	LCD
Output	4-20 mA, HART
Housing Material	Stainless steel
Certifications	ATEX, IECEx, UL, CSA, SIL 2
