GB
ELECTRICAL INSTALLATION MSA
26 ULTIMA
®
X
3 TM
Remote Sensor Power Consumption
Sensor Type Maximum Power Consumption
CAT 4.5 W
XIR 5.0 W
E-Chem 1.5 W
RS485 Communications
Characteristics of the three-core cable:
Cross Sectional Area 0.5 mm
2
A = Transmit + / Receive +
B = Transmit - / Receive -
C = Common (GND)
Maximum cable length: Trunk - 1000 m, Branch - 18 m
Line Termination 120 Ω
