MST Impact NS5004 User Guide

Tracker Engine List
This section is used to congure the MST Tracker Engine(s) that the access point will send information
to. The available settings are listed below. Note that data can be passed to up to 2 MST Tracker Engine
instances.
Recommended SettingsDescriptionField
On or Off.Indicates whether the Tracker
Engine will be sent data.
Enable
Specic to each site.The IP address of the MST Tracker
Engine.
IP Address
Default is 1142.The UDP port that the Tracker
Engine listens for messages on.
Port
Default is 15 seconds.The period that status reports will
be sent from the Access Point to the
Status Update Interval
Tracker Engine. These status reports
are used by the Tracker Engine to
determine if the Access Point is up
or down.
These options are enabled by
default.
Indicates which devices will be
tracked by this Access Point.
AeroScout Tags Enabled
MST Wi-Fi Tags Enabled
Mobile Units Enabled
Advanced Settings
Drop non-exciter tag reports - If enabled, the Access Point will only send tag reports when the tag is
in an AeroScout Exciter eld.
This setting applies to tag reports that are sent to AeroScout Positioning Engines and MST Tracker Engines.
5.5.9 Configuring Ethernet Switch Ports
The WAC in slot 1 (located on the left side of the NS50) is used for conguration and management of
the switch processors in the network switch. It enables the ports on the switch and the 48V rail for the
Power over Ethernet (PoE) supply to be congured.
Revision C78NS50 User Guide
Conguration Using the Web Interface
