MST Impact NS5004 User Guide

IllustrationProcedureStep
Wind the rubber tape at an angle
back down towards the base of the
connection and cut the tape.
5
Cable tie and mount the coaxial
cable(s) so it is free from
obstructions.
6
Important: Check that all
unused antenna ports
remain covered with the
supplied dust caps. Check
there are no obstructions
near the antennas that could
hinder the radiation pattern.
3.11 Manual Reset and Reboot
The NS50 can be manually power cycled or reset to factory default settings as described below.
PictureDescriptionStep
Locate and identify the Reset button and
the Factory Default buttons for CPU 1
and CPU 2.
1
Revision C40NS50 User Guide
Installation

MST Impact NS5004 Specifications

General

Brand	MST
Model	Impact NS5004
Category	Switch
Language	English
