Lube oil system
ID 1 2
Lube oil operating temperature before engine, from R °C 75 75
Lube oil operating temperature before engine, to R °C 100 100
Lube oil temperature before engine, limit 1 L °C 103 103
Lube oil temperature before engine, limit 2 L °C 105 105
Lube oil operating pressure before engine, from R bar 6.5 6.5
Lube oil operating pressure before engine, to R bar 9.5 9.5
Lube oil operating pressure before engine, warning L bar 5.5 5.5
Lube oil operating pressure before engine, shutdown L bar 5.0 5.0
Fuel system
ID 1 2
Fuel pressure at engine inlet connection, min. (when engine is
starting)
L bar -
General operating data
ID 1 2
Cold start capability: air temperature (w/o start aid. w/o preheat-
ing) - (case A)
R °C 0 0
Coolant preheating: preheating temperature (min.) L °C 32 32
Firing speed, from R rpm 100 100
Firing speed, to R rpm 120 120
Capacities
ID 1 2
Engine coolant capacity, engine side (without cooling equipment) R Liters 63 70
Charge-air coolant, engine side R Liters 20 25
Engine oil capacity, initial filling (standard oil system) (option:
max. operating inclinations)
R Liters 92 114
Oil change quantity, max. (standard oil system) (option: max. op-
erating inclinations)
R Liters 80 102
Weights / main dimensions
ID 1 2
Engine weight, dry (basic engine configuration acc. to scope of
delivery specification)
R kg 2710 3180
Acoustics
ID 1 2
Exhaust noise, not attenuated - DL (sound power level LW, ISO
6798, +3 dB(A) tolerance)
R dB(A) 130 131
Engine surface noise with attenuated intake noise (filter) - DL
(sound power level LW, ISO 6798, +2 db(A) tolerance)
R dB(A) 122 123
MS15054/03E 2018-07 | Technical Data | 39
TIM-ID: 0000065013 - 004
