3
Product description
Display Application Software
USB port for:
- USB memory device [➙ 24]
Port A
CAN bus port for:
- ISOBUS basic vehicle harness [➙ 15]
- Connection to the tractor CAN bus
Port C
Serial port for:
- GPS receiver [➙ 26]
- GPS TILT-Module
➙
Port B
See section: Pin assignment Port B [➙ 79]
ETH port
M12 port for:
CAM port
Port for an analog camera
Slot with the SD card
Display Application Software
The display is delivered with a range of installed application (apps). Most of these can be used
immediately. Even the non-activated applications can generally be tested for 50 hours. If you like
some specific application, you can order a license from Mueller-Electronics and unlock the full version
of the application.
The full versions of the following applications are installed on the display:
▪
- Application called “Service”.
The application Service allows you to:
– Configure the display.
– Enable and disable other applications.
– Enter license activation codes.
– Enable drivers for connected devices.
– Configure the GPS settings.
▪
- TRACK-Leader application.
The TRACK-Leader application allows you to work the field on exact parallel tracks.
The app contains several modules for which a license can also be activated:
– SECTION-Control: Automatic section control in order to minimize overlaps.
– TRACK-Leader AUTO: Automatic vehicle steering on the field.
– TRACK-Leader AUTO CLAAS: Automatic vehicle steering on the field for CLAAS tractors.
– TRACK-Leader TOP: Automatic vehicle steering on the field.
– TRAMLINE-Management: Tramline control using the current GPS position.
▪
- Tractor-ECU application
The Tractor-ECU application is used to record all settings around the tractor.
Here, you can e.g.:
– Enter the position of the GPS receiver.
– Set the GPS receiver as the speed signal source.
