Connecting and configuring external devices
GPS receiver
6
When the RTK signal is available again, the vehicle will be gradually steered towards the original
GPS position.
▪ deactivated
The parameter is deactivated.
Terrain compensation
Under this parameter the terrain compensation GPS TILT-Module is configured.
You can order the terrain compensation from Mueller-Electronics with the following item number:
30302495.
RTK or L band licence for SMART-6L
You will need a SMART-6L DGPS/GLONASS receiver and RTK license in order to work with RTK
correction signals.
To work with TerraStar correction signals, you need a SMART-6L DGPS/GLONASS receiver and at
least an L band license.
When purchasing a GPS receiver with an RTK or L band license, the license is entered at Mueller
Electronics. You only have to enter the licence yourself when it is purchased at a later date.
1. - Open the "Service" application.
2. Tap "GPS".
⇨ The "Settings" screen appears.
3.
- Open the license menu.
4. Tap "License code".
⇨ The "License menu" screen appears.
⇨ You can see the serial number and firmware version on the screen. You will need these
when ordering the license code.
⇨ If you are using the TerraStar correction signal, you will see information on the TerraStar
service and the expiry date of the TerraStar service.
⇨ Optionally, you can open the "Model number" screen to obtain information on the current
activation of the GPS receiver.
5. Enter the license code.
6.
- Confirm.
GSM modem for SMART-6L
If you are using the DGPS/GLONASS SMART-6L receiver with a GSM modem, you can adjust the
existing configuration.
1. - Open the "Service" application.
2. Tap "GPS".
3. The "Settings" screen appears.
4.
- Open the configuration menu.
