Connecting and configuring external devices
Connecting sensors to the display
6
31302713-02-US
V9.20191001
35
1. - Open the Service application.
2. Tap "Driver".
3. Tap "Auxiliary".
4. Mark "Auxiliary2".
5.
- Confirm.
6. Restart the display.
To configure the button assignment:
You have activated the “Auxiliary2” driver
1.
- Open the “Service” application.
2. Tap “Auxiliary”.
3. Tap “Auxiliary Editor”.
If the ISOBUS job computer supports the Auxiliary 2 protocol, a list appears of the job
computer functions.
If no list appears, the ISOBUS job computer does not support this protocol.
4. Tap the function which you want to assign to this button on the joystick.
A list of the buttons on the joystick appears.
You have two options for assigning the function to the joystick.
5. Option 1: On the joystick, press the button to which you want to assign the function.
Option 2: On the display, select the button to which the selected function should be assigned
and confirm with
.
The function will be assigned to the button and you can continue with the next function, until
you have assigned all of the functions.
6. Restart the display.
After restarting, the following notification appears on the main display screen: “Confirm the
assignments.” This notification appears after any restart.
7. “OK” - acknowledge the notification.
A list of recognized assignments appears on the display screen.
8.
- Confirm the assignments.
Connecting sensors to the display
The display provides you with the possibility of connecting a sensor or the tractor's 7-pole signal
socket to port B. This allows you for example to use the working position signal in the TRACK-Leader
parallel guide.
The work position sensor sold by Müller-Elektronik is fitted with a round 3-pin plug. You will need an
adapter cable to connect it to the display.
You must activate the work position sensor [ 53] and possibly the wheel sensor [ 52] or radar
sensor in the Tractor-ECU app and calibrate if necessary.
Procedure
6.3
