PAGE 18 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
SAFETY DECALS
(
ROLLER
)
4110
2 m
(6,6 ft.)
2 - 5 m
(6,6 - 16,4 ft)
2 m
(6,6 ft.)
60°
HLP46
3874
3960
2151
3213
AVIA NG
3953
4055
4097
max. 5m
Do not stretch cable further than 5m.
18 Hydraulic oil draining plug
19 Fuel tank
21 Diagram of the protected and the safe zone Get perfectly familiar with the machine operation accord-
ing to the operation manual.
17 Hydraulic oil level
20 Fuel draining plug
22 Coolant Use the coolant of required specication according to
Chapter 3.2.3.
23 California - Proposition 65 Warning Exhaust gases and their components, operating uids,
batteries and other machine accessories contain chemi-
cals known in the state of California to be substances
which may cause cancer, congenial defects and other re-
production problems.
When handling these substances, abide by relevant safe-
ty precautions.
Further information see www.p65warnings.ca.gov
24 Length of the remote control cable Do not run the infrared remote control cable to a distance
more than 5metres. The remote control may be pulled
out of the operator’s hand or the cable or remote control
may be damaged!
