RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23) — PAGE 37
INFRARED REMOTE CONTROL UNIT
8
9
9
Machine stop button (8)
The button is used to immediately stop the machine, switch o
the engine and activate the brakes.
The function is not available in case of loss of signal between the
remote control and the sensor on the machine.
In case of loss of signal, the machine stops automatically.
Do not use the button for normal machine shutdown.
Brake wear may occur.
Dead man’s buttons (9)
They are used to control the machine in special situations such
as loading the machine, working in partially covered trenches.
The buttons are for the operator when they are not in the safe
zone. To operate the machine, visual contact between the con-
troller and the operator is required, otherwise no signal trans-
mission will occur.
The function is only active when both buttons are pressed.
Operate the dead man function according to Chap. 2.7.7.
