PAGE 38 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
TRANSMITTER STATUS LED'S
47RAMMAX 1575
OPERATION MANUAL
2.6.2.1 Indicator lamps
Remote control charge indicator lamp (10)
The indicator lamp shows the battery charge status.
During charging, it ashes according to the current charge level.
Remote control battery error indicator lamp (11)
Cable control indicator lamp (12)
When the machine is operated by cable, the indicator lamp is
on.
Protected zone indicator lamp (13)
This indicator lamp lights up when the machine operator is out-
side the machine’s safe zone.
If the dead man function is activated, the safe zone is deacti-
vated. When approaching within 0.5 m of the machine, the stop
zone is activated and the machine stops automatically.
Protected zone indicator lamp (14)
This indicator lamp illuminates when the machine operator is in
the machine’s safe zone.
Safe zone deactivation indicator lamp (15)
The indicator lamp lights up when the machine’s safe zones are
deactivated.
If the machine operator approaches within a distance of less
than 0.5 m, the machine stops and switches o the working
functions, the indicator lamp starts ashing.
Use extra caution. There is a risk of injury or death by be-
ing run over by the machine!
Error message indicator lamp (16), (17)
It is used to indicate error messages.
Note
The indicator lamp (17) ashes during start-up if the controls are
not in their initial positions.
Charging of the remote control
Charging of the remote control is indicated by an indicator lamp
when the remote control is connected to the machine via cable.
Charging the remote control is possible even if the engine is
switched o.
Charging is indicated by an indicator lamp on the remote con-
trol
Charging of the remote control with the engine switched
o is limited to 2 hours only to avoid draining the ma-
chine battery. After 2 hours, charging is automatically
interrupted.
