PAGE 68 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
TRANSPORTING UNIT
1
2
3
How to secure the joint:
• Lower the arm (1), secure with the safety pin (2) and (3).
Risk of crushing through presence in the pivoting area
(danger zone)!
As soon as the machine is aligned, shut if o again.
DoNOT enter the area under the lifted load!
Upon loading completion, please return the safety arm
and cotters to their initial position.
Use corresponding, undamaged riggings of sucient
loading capacity.
To sling, please use only the lifting lugs on the Machine
designed for that purpose.
Only atrained slinger may carry out the slinging.
