PAGE 92 — RX1575 SERIES TRENCH ROLLER • OPERATION MANUAL S/N 3069933~ — REV. #0 (11/29/23)
MAINTENANCE
1
1
3.6 Individual Operations of Maintenance
Every 100 hours of operation
3.6.14 Lubricating steering cylinder, bearing
• Rotate the hydraulic cylinder steering fully to the stop in or-
der to grease the cylinder.
• Steer the machine briey to the right and the left. This caus-
es the bearing to be unloaded.
• Clean the grease nipple (1) before greasing.
• Connect the grease gun to the grease nipple.
• Press grease into the bearing until it visibly begins to ooze
out.
• Put the protective cover back on.
Note
Regrease the bearing after every cleaning / steam cleaning of
the machine.
