Video Grabber DGR-1000 User Manual - v. 1.4 (FW 1.9)
20
4.1.4.2. Output format
1
2
3
4
Figure 18: Output format subsection in the Video section on the Status page
Output format subsection groups parameters that relate to the format of data that is provided by the
Video Grabber. See the description of available parameters in the table below:
ID
Parameter
Description
1
Protocol
Selected captured data transmission protocol:
- Broadcast – captured data is broadcasted.
See Appendix B, p. 83
- NFS – captured data is saved on the NFS share
- SMB – captured data is saved on the SMB share
- RTSP – captured data is streamed using RTSP
2
FPM
(Frames per Minute)
Frequency of signal capture in Frames per Minute
3
Format
Selected captured data encoding format:
- BMP – Standard, uncompressed bitmap files
- PNG – Portable Network Graphics image files
- JPEG – JPEG image files
- JPEG2000 – JPEG2000 image files
- H.264 – H.264 stream
- Lossless – Lossless stream (Multisoft proprietary format)
4
FPS
(Frames per Second)
Frequency of signal capture in Frames per Second
Table 7: Descriptions of parameters available in the Output format subsection of the Video Section on the
Status page
