UsingtheRouter’sWebInterface 21

ToconfiguretheIPPipeinTCP/UDPClientmode:
1. IntheIPPipegroup,fromtheModedrop‐downlist,selectCLIENT.
2. FromtheProtocoldrop‐downlist,selectthedesiredprotocol,eitherTCPorUDP.
3. IntheServerIPAddressfield,typetheaddressofthefar‐en
dTCP
‐UDPserver.
4. IntheServerPortfield,typetheportvalueusedbythefar‐endTCP/UDPServer.
5. Incasetheprimaryserverisunavailable,intheSecondaryIPAddressfieldandintheSecondaryPort
field,typetheIPaddressandportnumber,respectively,ofthealternateTC
P/UDPserver.
6. FromtheConnectionActivationdrop‐downlist,selectaconnectionmethod.Optionsare:
 AlwaysOn
 CRThreecarriagereturnsmustbereceivedfromtheBluetoothsidebeforeTCP/UDPconnectionis
establishedtotheremoteserver.
7. FromtheConnectionTerminationdrop‐downlistselectadisconnectmethodfortheIPpipe.Options
are:
 AlwaysConnected
 SequenceAsequenceofcharactersreceivedfromtheBluetoothsideusedtodisconnecttheIPpipe
 TimeoutTheIPpipeconnectiondisconnectsiftheconfiguredtimerexpireswithnodatasentor
received
ClickSubmit.AfteryouarefinishedconfiguringtheBluetoothfeature,SaveandRestart.
Therouterimmediatelyconnectstothelocalbluetoothdevice.IfsuccessfultheStatusfielddisplays
Connected.IfIPPipeisco
nfiguredforSE
RVER,theIPconnectionisinitiatedbythefar‐endTCP/UDPclient.If
ModeissettoClient,therouterinitiatesconnectionsforthefar‐endTCP/UDPserverbasedontheconfigured
ConnectionActivationconditionsaremet.
