Chapter 6—Using the Software
MultiVOIP® Voice/Fax over IP Gateways 117
IP Statistics: Field Definitions
Field Name Values Description
IP Address n.n.n.n IP address of the MultiVOIP. For an IP address to be displayed here, the MultiVOIP must have
DHCP enabled. Its IP address, in such a case, is assigned by the DHCP server.
“Clear” button -- Clears packet tallies from memory.
Total Packets Sum of data packets of all types.
Transmitted integer
value
Total number of packets transmitted by this VOIP gateway since the last “clearing” or resetting of
the counter within the MultiVOIP software.
Received integer
value
Total number of packets received by this VOIP gateway since the last “clearing” or resetting of the
counter within the MultiVOIP software.
Received with
Errors
integer
value
Total number of error-laden packets received by this VOIP gateway since the last “clearing” or
resetting of the counter within the MultiVOIP software.
UDP Packets User Datagram Protocol packets.
Transmitted integer
value
Number of UDP packets transmitted by this VOIP gateway since the last “clearing” or resetting of
the counter within the MultiVOIP software.
Received integer
value
Number of UDP packets received by this VOIP gateway since the last “clearing” or resetting of the
counter within the MultiVOIP software.
Received with
Errors
integer
value
Number of error-laden UDP packets received by this VOIP gateway since the last “clearing” or
resetting of the counter within the MultiVOIP software.
TCP Packets Transmission Control Protocol packets.
Transmitted integer
value
Number of TCP packets transmitted by this VOIP gateway since the last “clearing” or resetting of
the counter within the MultiVOIP software.
Received integer
value
Number of TCP packets received by this VOIP gateway since the last “clearing” or resetting of the
counter within the MultiVOIP software.
Received with
Errors
integer
value
Number of error-laden TCP packets received by this VOIP gateway since the last “clearing” or
resetting of the counter within the MultiVOIP software.
RTP Packets
Voice signals are transmitted in Realtime Transport Protocol packets. RTP packets are a type or
subset of UDP packets.
Transmitted integer
value
Number of RTP packets transmitted by this VOIP gateway since the last “clearing” or resetting of
the counter within the MultiVOIP software.
Received integer
value
Number of RTP packets received by this VOIP gateway since the last “clearing” or resetting of the
counter within the MultiVOIP software.
Received with
Errors
integer
value
Number of error-laden RTP packets received by this VOIP gateway since the last “clearing” or
resetting of the counter within the MultiVOIP software.
RTCP Packets
Realtime Transport Control Protocol packets convey control information to assist in the
transmission of RTP (voice) packets. RTCP packets are a type or subset of UDP packets.
Transmitted integer
value
Number of RTCP packets transmitted by this VOIP gateway since the last “clearing” or resetting of
the counter within the MultiVOIP software.
Received integer
value
Number of RTCP packets received by this VOIP gateway since the last “clearing” or resetting of
the counter within the MultiVOIP software.
Received with
Errors
integer
value
Number of error-laden RTCP packets received by this VOIP gateway since the last “clearing” or
resetting of the counter within the MultiVOIP software.
