Chapter 4 – Configuring Your MultiVOIP
76 MultiVOIP® Voice/Fax over IP Gateways
The table that follows describes the fields of the RADIUS screen.
RADIUS Screen Field Definitions
Field Name Values Description
Enable Accounting Y/N When checked, the MultiVOIP accesses the accounting functions of the RADIUS
server.
Server Address n.n.n.n IP address of the RADIUS server that handles accounting (billing) for the current
MultiVOIP unit.
Accounting Port 1 - 65535 TDM time slot at which RADIUS accounting information is transmitted and received.
Retransmission
Interval
If the MultiVOIP sends out a packet to the RADIUS server and doesn't receive a
response in the retransmit interval, it retransmits that packet again and waits the
retransmit interval again for a response. How many times it does this is determined
by the setting in the Number of Retransmissions field.
Number of
Retransmissions
0 - 255
Shared Secret alpha-numeric Client encryption key for the current VOIP unit.
Select Attributes
(button)
-- Gives access to RADIUS Attributes screen. On Attributes screen, one can specify the
parameters to be tallied by the RADIUS server for accounting (usually billing)
purposes.
A secondary RADIUS dialog box, RADIUS Attributes, helps you customize accounting information that the
MultiVOIP sends to the RADIUS server. The MultiVOIP software logs data about many aspects of the call traffic
going through the MultiVOIP. The RADIUS Attributes screen lets you select the items to include in the
accounting reports sent to the RADIUS server.
“RADIUS Attributes” Definitions
Field Description Field Description
Select All Log report to include all fields
shown.
Start Date, Time Date and time the phone call began.
Channel
Number
Data channel carrying call. Call Mode Voice or fax.
Duration Length of call. Packets Received Total packets received in call.
Packets Sent Total packets sent in call. Bytes Received Total bytes received in call.
Bytes Sent Total bytes sent in call. Coder Voice Coder /Compression Rate used for call is
listed in log.
Packets Lost Packets lost in call. Prefix Matched When selected, the phonebook prefix matched
in processing the call is listed in log.
Outbound
Digits Sent
DTMF digits received by this
gateway from remote gateway (if
that DTMF set to "Out of Band").
Call Status Successful or unsuccessful.
Server Details The IP address of the traffic control server being used is displayed here if the call is handled through that
server. The Options field refers to non-mandatory server features that might be activated. For example, with
H.323, various H.323 Version 4 options might be listed.
From Details To Details
Gateway
Number
Originating gateway Gateway
Name
Completing or answering gateway
IP Address IP address where call originated. IP Address IP address where call was completed/answered.
Descript Identifier of where call originated. Descript Identifier of where call was completed/answered.
Options When selected, log does not use Silence
Compression and Forward Error
Correction by call originator.
Options When selected, log does not use Silence Compression
and Forward Error Correction by party answering call.
