Transport, Set-up, Putting into operation
Betriebsanleitung 07.06.2005 12/43
ba_c500_50s2GB06.fm ega
Cooling water
connection (optional)
Note on cooling water connection
When equipped with: Water cooling system
Water infeed
(infeed pressure max. 6 bar)
Water drain
Use a 1/2" water supply line for new installations.
Blow out supply line thoroughly before putting into operation.
The water drain should run downwards so that no remaining water can
flow backwards.
If water costs are high, return cooling in a closed water circuit can be more
economical. This also limits calcium deposits.
Cooling water requirements
– Input temperature max. 15 °C
– Filter element 50 µm
– pH value 6–7
– Concentration of:
Iron (Fe) and manganese (Mn) < 0.1 mg/l
Calcium (Ca) 22–50 mg/l
Magnesium (Mg) 13–30 mg/l
Free chlorine (Cl) < 0,1 mg/l
