multivac C 500 - Replacing the cover seal

Care and maintenance
Betriebsanleitung 07.06.2005 35/43
ba_c500_50s2GB06.fm ega
Replacing the cover
seal
Important information
Danger!
There is a danger of injuries due to the swinging movement of
the cover.
Do not allow anyone else near the danger area!
Only move the cover using the handle (1), not the levers (2).
When changing the lid seal, note that:
– The lid seal is made of silicone foam, therefore: Glue joint side with sil-
icone adhesive. Other adhesives may have poor adhesive properties.
– Non-rectification of defects established in the area of the the sealing
gasket can result in an inadequate vacuum.
2
2
1
2
1
3
1 Lid seal (position in the lid)
2 Glue joint side with silicone adhesive
3 Cover seal in cross section
