Transport, Set-up, Putting into operation
Betriebsanleitung 07.06.2005 15/43
ba_c500_50s2GB06.fm ega
Inert gas connection Note the safety instructions.
Caution!
The gas input pressure must not exceed 3 bar.
– Connect a gas hose with an internal diameter of 8 mm (max. length:
5 m) from the pressure reducer (B) of the gas tank to the nipple.
– Open the stop valve of the gas tank (C).
– The pressure reducer (B) on the gas bottle should be set to: 3 bar.
– Open the shut-off valve (C) on the gas bottle.
– Pull pouch opening over the gas flushing jet so that the inert gas flows
directly into the pouch. See chapter "Packaging" for more information.
C
B
0,7 - 2,5 bar
Di 8 mm
mm
3 bar
max. 5 m
