Control panel
Betriebsanleitung 07.06.2005 2/43
ba_c500_50s2GB06IVZ.fm ega
Control panel
1 Control panel, control unit
1.1 CONTROL UNIT ON/OFF key
1.2 Digital display
1.3 Display value in millibar
1.4 Display value in seconds
1.5 PROGRAM keys 1 to 6
1.6 INCREASE VALUE key
1.7 DECREASE VALUE key
1.8 SEALING key
1.9 INERT GAS key (optional)
1.10 VACUUM key
1.11 RAPID VACUUM STOP key
2 MACHINE ON/OFF main switch
mbar
s
STOP
P1 P2
P4P3
P5 P6
I/O
0
I
2
1
1.11 1.10 1.9 1.8 1.7 1.6 1.5
1.1 1.2
1.3
1.4
