Technical data
Betriebsanleitung 07.06.2005 39/43
ba_c500_50s2GB06.fm ega
Technical data
1320
815
1600
1050
750
Height (lid open): 1320 mm
Height (lid closed): 1065 mm
Width: 1600 mm
Depth: 1050 mm
Electric voltage: see type plate
Permitted operating temperature range: 0...45°C
Permitted temperature range for storing the machine: -25...+85°C
Relative humidity: 5...85 %, Non-condensing
Nominal power: see type plate
Weight: 480 kg (without pump)
630 kg (w. pump 160 m
3
/h)
680 kg (w. pump 250 m
3
/h)
Useable chamber size: Width 670 mm, Depth 750 mm
Chamber height: 200 mm
Sealing length: 650 mm
Built-in vacuum pump: 140 or 250 m
3
/h
Reachable ultimate pressure: approx. 1 mbar
Packing capacity: approx. 2 to 3 cycles/minute, depend-
ant on set ultimate pressure
