Working area sound pressure level
Betriebsanleitung 07.06.2005 42/43
ba_c500_50s2GB06.fm ega
Working area sound pressure level
Basis: DIN EN ISO 3744/3746 and 11 204
Measuring unit: Precision sound level meter DIN 45 633 IEC 651,
class 1, Dynamic characteristics: slow.
Applicable accuracy class: 2
Machine type: C 500 in new condition.
Measured values
Explanation of the working area sound pressure level L
pA
The working area sound pressure level L
pA
listed in the table is corrected
to take account of external noise and ambient surroundings.
If the machine is set up in a room where sound reverberates, the actual
noise that the workers are exposed to may be higher.
This value is applicable to new or overhauled machines with optimal set-
tings at the time of delivery. A higher level could result during operation
due to wear or modified settings.
Working area sound pressure level L
pA
in dB (A)
Machine type Working area A
C 500 72 dB (A) (without vacuum
pump)
80 dB (A)
A
A
A
1,6 m0,50,5
