35
SPECIFICATIONS
ENGINE (20HP):
Make Briggs & Stratton
Model ELS
Horsepower 20 @ 2750 rpm
Displacement 540cc
CHASSIS:
Fuel Tank Capacity 3.25 Gallons (12,3 L)
Rear Wheels Tire Size: 18 x 8.5-8
Inflation Pressure: 10-12 psi (0,69-0,83 bar)
Front Wheels Tire Size: 11 x 4-5
Inflation Pressure: 18-20 psi (1,24-1,30 bar)
TRANSMISSION:
Type Hydro-Gear EZT ZC-AHBB-2A7B-1DPX
Hydraulic Fluid 20W-50 Premium Engine Oil
Continuous Torque 115 ft. lbs. (155.9 Nm)
Output
Maximum Weight 340 lbs (154.2 kg)
per Axle
NOTE: Specifications are correct at time of printing and are subject to change without notice.
The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engineers)
code J1940 (Small Engine Power & Torque Rating Procedure), and rating performance has been obtained and corrected in
accordance with SAE J1995 (Revision 2002-05). Torque values are derived at 3060 RPM; horsepower values are derived at
3600 RPM. Actual gross engine power will be lower and is affected by, among other things, ambient operating conditions and
engine-to-engine variability. Given both the wide array of products on which engines are placed and the variety of environmental
issues applicable to operating the equipment, the gas engine will not develop the rated gross power when used in a given piece of
power equipment (actual “on-site” or net horsepower). This difference is due to a variety of factors including, but not limited to,
accessories (air cleaner, exhaust, charging, cooling, carburetor, fuel pump, etc.), application limitations, ambient operating
conditions (temperature, humidity, altitude), and engine-to-engine variability. Due to manufacturing and capacity limitations,
Briggs & Stratton may substitute an engine of higher rated power for this Series engine.
