MUTOH VJ-1638X User Manual

Handling the printer VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
208 4.4 Operating from Operation panel
4.4.3 Cutting media
This section explains how to cut media.
If Media ejection mode is set to Auto Cut, the printer cuts the media automatically after printing.
5.1.6 Output Mode menu
If you press the [Cutting] key on Operation panel more than two seconds while Operation panel is
Normal, you can cut the media at the desired position.
Follow the procedure below to cut the roll media.
1. Confirm that Operation panel is Normal.
2. Press the [Cutting] key on Operation panel for more than 2 seconds.
• The printer feeds the roll media to the length of the margin and cuts the media.
NOTE
• When loading the new roll media, cut the front edge of the media if it is not straight.
• The cutter is a consumable component.
Replace it periodically.
6.1.4 Replacing Cutter
• When the the media detection is set to "Off", the media cannot be cut automatically.
5.1.4 Media Set menu

MUTOH VJ-1638X Specifications

General

Max Resolution	1440 x 1440 dpi
Print Technology	Piezo inkjet
Print Width	64" (1625 mm)
Ink Type	Eco-Solvent
Media Thickness	1.5 mm
Connectivity	USB, Ethernet
Ink Colors	C, M, Y, K
Operating System Compatibility	Windows
Power Requirements	50/60Hz
