MUTOH VJ-1638X User Manual

VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL Maintenance
6.2 Cleaning the printer 323
6.2.3 Head cleaning
If the printed data is unexpectedly faint or dots are missing, clean the Print head and Nozzles by
performing Head cleaning.
Follow the procedure below to perform Head cleaning.
CAUTION
• Turn on the printer and then perform Head cleaning.
NOTE
• When not using the printer for a long period (one week or more), perform Head cleaning once a
week. If not performing Head cleaning, Print head is clogged. Doing so will preserve print quality.
1. Confirm that Operation panel is Normal.
2. Check that Media loading lever is lowered.

MUTOH VJ-1638X Specifications

General

Max Resolution	1440 x 1440 dpi
Print Technology	Piezo inkjet
Print Width	64" (1625 mm)
Ink Type	Eco-Solvent
Media Thickness	1.5 mm
Connectivity	USB, Ethernet
Ink Colors	C, M, Y, K
Operating System Compatibility	Windows
Power Requirements	50/60Hz
