Panel setup menu VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL
236 5.1 Setup menu
Effect menu
Sets up the Effect menu.
Set up this menu when you want to improve print quality by adjusting the set print mode.
• The print quality may not be improved depending on the printing condition.
*1 The initial values of effect differ as shown below depending on the selected print mode.
Setup item Setting Description
Effect <None> *1 The Effect function is not used.
Wave The printing joint will be the wave form.
The print quality may be improved than None.
Fine&Fuzz The printing joint will shade off as the wave form.
Perform the printing at slower speed than "Wave".
<Fine&Fog> *1 The printing joint will shade off.
Set this when there is horizontal unevenness in Fine&Fuzz
Prints at a slower speed than Fine&Fuzz
A-S.Fine&Wave Performs "Wave" printing using the left side of the of Print
head.
Since only half of Print head nozzles are used, printing speed
becomes a half of "Wave".
Set up this menu to improve the print quality compared with
"Fine&Fuzz". If used when one side of the nozzles are
clogged, quality deterioration may be avoided.
B-S.Fine&Wave Performs "Wave" printing using the right side of the of Print
head.
Since only half of Print head nozzles are used, printing speed
becomes a half of "Wave".
Set up this menu to improve the print quality compared with
"Fine&Fuzz". If used when one side of the nozzles are
clogged, quality deterioration may be avoided.
— • [Enter] key: saves the setting and shifts to the previous
menu.
• [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.1 Print Mode menu
Print Mode Initial effect value
Quality 1 to 4 Fine&Fog
Graphics 1 to 2
Banner 1 to 2
Banner 3 to 4 None
To Next Page
