13.4 Table of System Registers
13 - 19
Item No. Name Default
value
Descriptions
Tool
port
410 Unit No. setting 1 1to99
port
set-
412 Selection of modem connection Disabled Enabled/Disabled
set
ting
413 Communication format setting Character bit:
8 bits,
Parity check:
“with, odd”
Stop bit: 1 bit
Enter the settings for the various items.
Character bit: 7bits/8bits
Parity chk: none/with odd/with even
Stop bit: 1bit/2bits
415 Communication speed (Baud rate)
setting
9600 bps 2400 bps
4800 bps
9600 bps
19200 bps
38400 bps
57600 bps
115200 bps
COM.
1
port
410 Unit No. setting 1 0to99
1 port
set-
ting
412 Communication mode setting Computerlink Computer link
General communication
PLC link
Selection of modem connection Disabled Enabled/Disabled
413 Communication format setting Character bit:
8 bits,
Parity check:
“with, odd”
Stop bit: 1 bit
Enter the settings for the various items.
Character bit: 7bits/8bits
Parity chk: none/with odd/with even
Stop bit: 1bit/2bits
The following setting is valid only when the
communication mode specified by system
register 412 has been set to “General com-
munication”.
End code (Terminator): CR/CR+LF/None
Start code (Header): STX not exist/STX
exist
415 Communication speed (Baud rate)
setting
9600 bps 2400 bps
4800 bps
9600 bps
19200 bps
38400 bps
57600 bps
115200 bps
416 Starting address for received buffer of
general (serial data) communication
mode
0 0 to 32764
417 Buffer capacity setting for data
received of general (serial data)
communication mode
2048 0 to 2048
Note
The communication format when using the PLC link is fixed at
the following settings:
the data length is 8 bits, odd parity, stop bit is 1.
The communication speed (baud rate) is fixed at 115,200 bps.
