10 Cross-mode functions
102 FieldMan Narda
1) LAL: Low, ALs; HAL: High ALs; Limbs: Limbs ALs; Thermal: ALs Thermal; GP: General Public;
Occ: Occupational; Unrest: Unrestricted; Restrd: Restricted; Unctrld: Uncontrolled; Ctrld:
Controlled
10.2.2 Standards for LF probes
For the LF probes, the standard is used to display the limit curve graphically in the spec-
trum or to display the measurement result as a normalized spectrum. The selection is
made under MEASUREMENT SETTINGS > Standard. The same table applies as for
HF probes. The selection None is used to switch off the display of a limit value curve in
the SPECTRUM operating mode.
10.3 Offset correction – Zero
⇒ See measurement settings in the operating modes.
Man
ual offset correction is only required for the HP-01 probe. The correction process is
started by triggering Zero in the measurement settings and is recommended before mea-
suring small static fields. For offset correction of the HP-01, the sensor tip must be placed
in a zero field chamber before the correction process is started, in order to exclude the
influence of external fields and especially t
hat of the earth's magnetic field.
Perform the offset correction:
1. Press SK2, then select Zero.
↳ A dialog box opens.
2. Follow the instructions in the dialog box.
3. Continue with SK4 or cancel with SK1.
↳ The progress and completion of the offset correction are displayed.
4. Follow the instructions in the dialog box.
5. Press the Back key to return to the measuring mode.
SC6-2015 Unctrld NS 3 kHz to 10 MHz
SC6-2015 Ctrld NS 3 kHz to 10 MHz
SC6-2015 Uncontrolled 0.1(1) MHz to 300 GHz
SC6-2015 Controlled 0.1(1) MHz to 300 GHz
Standard
1)
Frequency range
